| Hydraulic Filter AL232896 P958404 SH66209 HY90562/1 Parameter: | |
| Part Number | AL232896 P958404 SH66209 HY90562/1 |
| Brand | Tamfiney |
| Weight | 306 g |
| Height | 180 mm |
| Outer Diameter | 73 mm |
| Inner Diameter | 32 mm |
| Material | Plastic & Glass fiber |
| Filter Media | Glass fiber with mesh blend |
| Typical Working Pressure | Up to approx. 6–10 bar |
| Filtration | Approx. 5–10 micron |
| Temperature Rating | Up to approx. 100–120°C |
| Minimum Order | 50 PCS |
| Place of Region: | Zhejiang, China |
| Payment Terms: | T/T |
| Price Terms: | FOB |
| Lead Time: | 30 to 50 days based on order quantities |
| Market Type: | After Market |
| Current Export Market: | Southeast Asian,North America, South America, Western Europe, Eastern Europe, Africa, Oceania |
What does the AL232896 filter fit?
- John Deere 6000 Series (e.g., 6090M, 6100M, 6110M, 6120M, 6130M, 6140M, 6150M, 6155M, 6170M, 6190M)
- John Deere 6R Series (e.g., 6090RC, 6105R, 6110R, 6115R, 6125R, 6130R, 6145R, 6150R, 6155R, 6170R, 6195R, 6210R, 6215R)
- Select 6225, 6330, 6430, 6534, 6630, 6830, 6930, 7130, 7230, 7330, 7430, and 7530 models
Premium John Deere AL232896 P958404 Hydraulic Filter SH66209 HY90562/1
Q: Where is the hydraulic filter located on a John Deere tractor?
The hydraulic filters of John Deere tractors are mainly located on the outer side of the rear axle/gearbox housing, and the specific positions of different horsepower models are clearly distinguished:
Location distribution of mainstream models
- Small and medium horsepower models (904/12404/5E series): The hydraulic filter is mostly a rotary type, directly exposed on the right side of the rear axle housing, near the outlet pipe of the hydraulic oil tank. The appearance is a black cylindrical metal tank with clear John Deere logo, which can be seen directly when standing on the right side of the tractor and bending over.
- High horsepower models with PowrQuad transmission (6M/7M series): The hydraulic filter (labeled as component C) and transmission oil filter are arranged side by side, located below the differential housing, diagonally above the rear axle drain screw A, and can only be found by bending over to the side of the tractor's rear axle.
- Models with front four-wheel drive HFWD: In addition to the main hydraulic filter, the filter element of the front axle hydraulic system is hidden in the upper guard plate of the front axle differential, and the guard plate near the front wheels needs to be removed first to see it.
Quick Search Tips
- Follow the oil outlet pipe of the hydraulic oil tank towards the oil pump direction, and the first rotating component connected to the pipeline is the hydraulic filter.
- The hydraulic filter and transmission oil filter of some models are integrated together, and the English words "Hydraulic Filter" will be printed on the housing to distinguish it from the transmission oil filter.
- Before replacing, it is necessary to start the tractor and operate the hydraulic handle several times to increase the oil temperature. After turning off the engine and locking the vehicle, unscrew the old filter element to avoid the cold oil having high viscosity and being unable to move
Q: What is the price of a John Deere tractor hydraulic filter?
The mainstream price range for John Deere tractor hydraulic filters on the market is USD7 to USD30, with significant differences in specific pricing for different models and channels.
Price influencing factors
- Purchase quantity: When purchasing more than 100 pieces in bulk, the unit price of some models can be as low as USD10 or even lower, which is about 40% cheaper than the retail price.
- Channel type: Overseas original accessories have higher prices, and the original filters for some 5R/7R series models are priced at about $518. while chinese replacement models only require a little comparing to the OEM.
- Material and process: Using imported fiberglass and high filtration precision models, the price will be 30% -50% higher than ordinary paper filter.
