| Hydraulic Filter 225-4118 2254118 P165675 HF6587 Parameter: | |
| Part Number | 225-4118 2254118 P165675 HF6587 |
| Brand | Tamfiney |
| Weight | 2950 g |
| Height | 295 mm |
| Outer Diameter | 121 mm |
| Inner Diameter/ Thread Size | 1 3/4-12 UN |
| Material | Metal/Aluminum & Glass fiber |
| Filter Media | Glass fiber with mesh blend |
| Casing | Painted steel outer body with perforated steel internal support |
| Typical Working Pressure | Up to approx. 6–10 bar |
| Filtration | Approx. 5–10 micron |
| Temperature Rating | Up to approx. 100–120°C |
| Minimum Order | 100 PCS |
| Place of Region: | Zhejiang, China |
| Payment Terms: | T/T |
| Price Terms: | FOB |
| Lead Time: | 30 to 50 days based on order quantities |
| Market Type: | After Market |
| Current Export Market: | Southeast Asian,North America, South America, Western Europe, Eastern Europe, Africa, Oceania |
Applications:
- Ingersoll Rand Compressors: Fits select Ingersoll Rand compressor systems and fluid/oil filtration setups (cross-referencing parts like Ingersoll Rand 0SPLF5624).
- Hydraulic & Return Line Assemblies: Designed primarily for use in Donaldson HMK05 and HMK25 spin-on assembly housings.
Professional 225-4118 2254118 P165675 HF6587 Spin-on Duramax Hydraulic Filter
